↩ 013. Linux a.out quine in 44 bytes ↩

Sun, 17 Mar 2024 04:57:16 +0100

Susam Pal's Self-Printing Machine Code (on mastussy) demonstrates a 12-byte dos program copying its image to the standard output. This platform lends itself well to the problem, since executables are allowed to be bare code and copied to a fixed offset, naturally advantaging it over real systems like unix. Nevertheless, the unix a.out header is only 32 bytes and the entire image is similarly mapped at a well-known location; too bad Linux doesn't support a.out.

But Debian GNU/Linux 0.93 will be the last release that uses the a.out binary format., and 0.93R6 is, obviously, readily available to install. A musty 1995 vintage, for which you definitely want to consult the installation guide, but 1995 debian-installer is irrevocably and unfalteringly debian-installer. There are, of course, some fundamental issues with running a 30-year-old system:

• KVM breaks it completely (not that it needs acceleration)
• no SCSI, and the installation is multi-floppy, so google "qemu monitor change floppy" is in full effect
• it needs a little bit of RAM (at least four megabytes), but not too much; the qemu default of 128M is too much
• similarly for the disk – suppress the instinct of defaulting to 4G, and given a new disk partition of at least 40 megabytes, 128M works
• ACPI doesn't exist yet. the system halts by halting
• it will probably Just hang at one point; lynx will cause a kernel oops; (address resolution in) ping will randomly hardloop/segfault
• there is no DHCP-enabled config in the installer, and you don't need it because qemu doesn't emulate any supported ethernet card
• this means that the only I/O to the world is by floppy and serial
• boot is floppy-only as well

overall qemu-system-i386 -m 32m -fda boot.bin -hda rootfs -boot a -fdb debs.tar works, and the most annoying limitation is that the floppy will be truncated at 2.8M, so you can't tar up every deb at once; not that it really matters because strace/gdb/binutils/gcc are the only relevant ones not on the installation floppies.

This draws heavily from the aforelinked BGGP4 submission, where I had been robbed of my winning submissions for both the binary and shell program categories. Nevertheless, this allows for more interesting packing; given the annotated program:

0	cc 00 64 00	; a_midmag
4	0C 00 00 00	; a_text
8	00 00 00 00	; a_data
12	b0 04      	; a_bss eax=4	mov    al,0x4	number=__NR_write
14	EB 10      	;            	jmp    +16
18	00 00 00 00	; a_syms
22	0C 10 00 00	; a_entry
26	00 00 00 00	; a_trsize
30	00 00 00 00	; a_drsize
32	31 db      	; ebx=0     	xor    ebx,ebx	fd    =0
34	31 c9      	;           	xor    ecx,ecx
36	b5 10      	; ecx=0x1000	mov    ch,0x10	buf   =loadaddr
38	31 d2      	;           	xor    edx,edx
40	b2 2C      	; edx=44    	mov    dl,44	count =progsize
42	cd 80      	; syscall() 	int    0x80
44

note that a_midmag (the magic), a_text (the size of the program text immediately following the header; Linux has started requiring this (and, thus, the file size) to be page-aligned by 2.6), and a_data (the size of program data, following the text) are fixed parameters while a_trsize and a_drsize must be 0; a_bss can be anything, since it describes the initial allocation to map after the program data, while a_syms can, empirically, sometimes have a non-zero low byte.

While COMs are loaded at 0x100 and a.outs are loaded at 0x1000, the start address for COMs is also 0x100, while for a.outs it's a_entry. "Real" a.outs in the distribution include the libc runtime entry point at start of the program text, and thus a_entry is unwaveringly 0x1020 (0x1000 + the 32 header bytes); except in this case it's a_bss, into which the first instruxion is packed.

While Susam's program amounts to, effectively, a "write a buffer, then return" implementation (down to exiting with ret) in 12 bytes, this is an exercise in zeroing registers, since it amounts to

	write(0, 0x1000, 44);

in 44 bytes – conveniently an even 32 more, matching the header size. The astute reader will've noted that it actually executes 16 bytes to do so, but if all registers were clear on entry this would've been just 10.

There is no explicit exit, since the 270M of zeroes (allocated by a_bss=0x10eb04b0) decode to add byte [eax], al which instantly segfaults, and, if you don't disable coredumps, fills your disk.
